Elastic Alloys HOME >> Elastic Alloys
PRODUCTS:Elgiloy Alloy
GRADE:3J21、3J22、3J23
PRODUCTION STANDARD:YB/T5253-1993、YB/T5252-1993、YB/T5243-1993
Views:1528
  • PRODUCTS DETAILS
  • SPECIFICATION

    Introduction:


     This Cobalt-Chromium-Nickel alloy also known as Elgiloy gives a combination of high strength, ductility and good mechanical properties and is age hardenable. Phynox also has excellent fatigue life, corrosion resistance in numerous environments and is non-magnetic. This alloy is recommended where a high resistance to corrosion and / or low relaxation at temperatures up to 380°C are required.








    *Elgiloy alloy(Co40CrNiMo),AMS 5833,UNS R30003Chinese 3J21

    Relative Grade

    Russia

    U.S.A.

    Japan

    France

    Standard

    40КНХМ

    Elgiloy

    NAS604PH

    KRN

    phynox

    YB/T5253-1993

    Grade and Chemical Composition (see Table 1)

    Table 1 Grade and Chemical Composition of 3J21



    Grade

    Chemical Composition(%)

    C

    Mn

    Si

    P

    S

    Ni

    Cr

    Co

    Mo

    Fe

    3J21

    0.070.12

    1.702.30

    0.60

    0.010

    0.010

    14.021.0

    19.021.0

    39.041.0

    6.507.50

    Bal


    Remark: The size and shape must be tally with the standard of GB/T15006 for “elastic alloy”.

    Mechanical Property(see Table 2)

    Table 2 Mechanical Property

    Shape

    Delivery State

    Thickness&Diameter

    /mm

    Group

    Mechanical Property

    Tensile Strength

    (ób/Mpa)

    Elongation

     δ(%)

    Strip

    Cold Rolling

    0.202.50

    A

    11751470

    5

    B

    14701765

    3

    Wire

    Cold Drawn

    0.205.00

    A

    12751570

    B

    15701865

      Physical Property (see table 3)

    Physical Property of 3J21 after aged

    Item

    Target

    Modulus of Elasticity   E/Mpa

    196000215500

    Shear Modulus  G/Mpa

    7350083500

    Density (g/cm3)

    8.4

    Mean coefficient of linear expansion20-100°C/(10-6/K)

    14

    Resistivity ρ /(μΩ·m)

    0.92

    Magnetic Rate k/106

    501000

    Remark: The K value is the value of the centimeter gram second system.

      Use: It is applied to make antimagnetic, corrosion proof and long range elasticity alloy for elastic cell.







    Specification:

    Sheet/Plate, Bar/Rod/Wire/Coil


    Size Range:

    *Sheet---thickness 0.05mm~2.50mm, width:10.0~210mm,Condition: cold rolled, bright,

    *Plate---thickness 2.5mm~40.0mm,width:300mm,Condition: cold rolled, hot rolled

    *Round Wire---Dia 0.1mm~Dia 7.0mm,Condition: cold drawn, bright

    *Flat Wire---Dia 0.5mm~Dia 7.0mm,length:1000mm,Condition:flat rolled, bright

    *Bar---Dia 7.0mm~Dia 10.0mm,length:2000mm,Condition:cold drawn,bright


    Note: we could do any other products with specified technical standard, say, ASTM,SAE,DIN,S.E.W.,JIS,ISO,IEC,NF,BS,ΓОСТ.PLS contact us for more information: Tel: +86-29-89396652 or e-mail us at: Sales@xaleipeng.com
